Wall mounted scale with folding table iL Special 150T/SP

Electromechanical load receptor without lever work entirely made of s/s for wall mounting
Electromechanical load receptor iL Special 150T/SP can be freely positioned at the wall. This provides optimal working conditions based on your environment and requirements. The fold-up load platter makes room when space is at a premium. This robust load receptor was developed for wet and harsh ambient conditions. Therefore, all functional and mounting parts are made of stainless steel – for an optimal long-term accuracy and a high wear-resistance.The open design allows particularly easy cleaning. An integrated rear wall ensures exact weighing results and at the same time hygiene and cleanliness of your products and the wall behind.Our verifiable load receptor iL Special 150T/SP is available in different weighing ranges, as a dual range scale and dual interval scale. The load receptor supports all Bizerba weighing terminals.

Hoogtepunten

  • Electromechanical load receptor without lever mechanism
  • Complete model in 1.4301 stainless steel for wall mounting
  • Weighing terminal with flexible measuring cable (standard 6 m)
  • can be placed anywhere for optimal workstation organization

Productafbeeldingen en technische informatie kunnen afwijken en zijn mogelijk niet beschikbaar in uw land.

Toepassingsgebieden

  • Single point load receptor as wall mounted scale with table for goods receiving, warehousing and shipping; suitable for load capacities up to 150 kg.
  • In combination with Bizerba weighing terminals it can be used for counting, dosing, formulation, checking and commissioning

Details en opties

Specificatie Feiten Details
Load cell PC6
Verificationable
Maximum load 331lbs
Temperature range 14 °F to 104 °F Operation
Installation type Wall
Dimensions (L x W x H)/(D x W x H) 550 x 445 mm
Weight 27 kg
Supply medium Supply by weighing terminal
Accuracy class III
Weighing range 150 kg
60/120 kg
60 kg
60/150 kg
60 kg
30/60 kg
30 kg
30/60 kg
30 kg
150 kg
e=50 g
e=0,02/0,05 kg
d=20 g
d=0,02/0,05 kg
e=20 g
d=10/20 g
e=10 g
e=10/20 g
d=10 g
d=50 g
Material Stainless steel V2A
Installation area (L x W) 550 x 518 x 500 mm
Ramps
Load plate version Screwed
Approval information R76 = NAWI, Non automatic weighing instrument
